Type：Passive three-way frequency
Usable bandwidth(-10 dB)：67Hz-18kHz(预设)
Maximum SPL¹：139dB(preset)
Coverage angle(-6 dB)²：Coverage angle(horizontal) 80° The tilt angle is set in increments of 0°-14° 1°
Transducers：LF:2x10”,MF:1x8”,HF:2x2.5”
Rigging：Connector 2xNLT4 F/M
Physical data WxHxD：700x310x460mm 27.5x12.2x22.18in
Weight (net)：34kg/75lb
Type：Passive three-way frequency
Usable bandwidth(-10 dB)：67Hz-18kHz(预设)
Maximum SPL¹：139dB(preset)
Coverage angle(-6 dB)²：Coverage angle(horizontal) 80° The tilt angle is set in increments of 0°-14° 1°
Transducers：LF:2x10”,MF:1x8”,HF:2x2.5”
Rigging：Connector 2xNLT4 F/M
Physical data WxHxD：700x310x460mm 27.5x12.2x22.18in
Weight (net)：34kg/75lb
