Type：Class D amplified controller with PFC
Output Power：4×2600W at 4 ohms / 4x1400W at 8 ohms
Architecture:96 kHz/32-bit floating point DSP4 in x 4 out / AVB,AES and analog
Processing:Array Morphing / Multiband EQ / Air absorption compensation filter / 1000 ms delay per output / L-DRIVE advanced system protection
Network:2× Ethernet AVB 1Gb/s ports,Milan-certified
Control:LA Network Manager / Q-SYS™,Crestron®,Extron® and SNMP
Type：Class D amplified controller with PFC
Output Power：4×1000W at 4 ohms / 4x1000W at 8 ohms
Architecture：96 kHz/32-bit floating point DSP4 in x 4 out / Bridge modes:4×3,4×2,4×1. / AVB,AES and analog
Processing：Array Morphing / Multiband EQ / Air absorption compensation filter / 1000 ms delay per output / L-DRIVE advanced system protection
Network：2× Ethernet AVB 1Gb/s ports,Milan-certified / Seamless network redundancy
Control：LA Network Manager / Q-SYS™,Crestron®,Extron® and SNMP
Professional digital power amplifier
Output Power:4x800 W/8Ω 4x 1600 W/4Ω
Routing Matrix: 4x4 flexible routing matrix
Sampling frequency ：44.1-192KHz(AES/EBU)
Available bandwidth: 20Hz-20kHz
Dynamic range ：>140 dB
Input：+22dBu(balanced,THD 1%)
Harmonic distortion：<0.05%(at8Ω , 6OW output)
Analog impedance: 22KΩ
Digital inputs: AES/EBU XLR balanced
Input gain: 32dB
Power supply: 100V-240V~±10% 50-60Hz
Cabinet size: 88 x 432 x 420mm
Box weight: 14.5Kg
TYPE：Digital Signal Processing
Sampling rate：96 kHz/27 Bit ADC/24 Bit DAC
Sampling Digital AES/EBU：48 kHz/96 kHz
Maximum output power per channel
CF = 6 dB at 4 / 8 ohms：4 x 1000/800 W
CF = 12 dB at 4 / 8 ohms：4 x 1600/800 W
S/N ratio (unweighted, RMS)
Analog input：> 104 dBr
Digital input：> 106 dBr
Rated mains voltage：100 - 240 V, 50 - 60 Hz
Dimensions (h x w x d)：2 RU x 19" x 460 mm/18.1"
Weight：10.8 kg/23.8 lb
TYPE：Digital Signal Processing
Sampling rate：96 kHz/27 Bit ADC/24 Bit DAC
Sampling Digital AES/EBU：48 kHz/96 kHz
Maximum output power per channel
CF = 6 dB at 4 / 8 ohms：4 x 800/800 W
CF = 12 dB at 4 / 8 ohms：4 x 1600/800 W
S/N ratio (unweighted, RMS)
Analog input：> 104 dBr
Digital input：> 106 dBr
Rated mains voltage：100 to 240 V, 50 – 60 Hz
Dimensions (h x w x d)：2 RU x 19" x 530 mm/20.9"
Weight：15.6 kg / 23.4 lb
